HA-80RG

Basic Rigid Windsock Assembly

The HA-80RG windsock assembly is your essential wind direction indicator Discover the straightforward reliability of the HA-80RG Windsock Assembly, offered by Holland Aviation. Made to serve as a consistent wind direction indicator, this assembly comes in three versions: unlighted, externally lig... Read more
Request a quote

More information or advice?

Description

The HA-80RG windsock assembly is your essential wind direction indicator

Discover the straightforward reliability of the HA-80RG Windsock Assembly, offered by Holland Aviation. Made to serve as a consistent wind direction indicator, this assembly comes in three versions: unlighted, externally lighted, and internally lighted, catering to your specific needs. The external lighting unit illuminates the windsock from above with 4 floodlights. The internal lighting unit consists of a swivel equipped with two heavy-duty stainless steel bearings, providing illumination from within the windsock. All lighted windsock assemblies are equipped with a low-intensity obstruction light.



Durable and environmentally friendly

Made with care from quality materials, the windsock assembly ensures durability and accuracy in wind measurement. The illuminated windsock assemblies feature energy-efficient LED lights, contributing to their eco-friendliness. Additionally, using high-quality, durable materials further enhances their environmental sustainability. For windsock needs in salty maritime settings, consider exploring the HA-80RG SST – a windsock assembly constructed from stainless steel.



Key Features of the HA-80RG windsock assembly:

  1. Reliable wind direction: The windsock assembly serves as a dependable wind direction indicator, providing accurate wind readings and essential information.
  2. Insightful wind data: By combining wind direction with the windsock’s orientation, you can estimate wind speed, empowering better decision-making.
  3. Low maintenance: The windsock assembly is designed to minimize maintenance requirements, making it a cost-effective choice.
  4. Easy maintenance: Featuring a tiltable mast, the HA-80RG simplifies upkeep and windsock replacement.
  5. Versatile sizing: Designed for windsocks up to 60cm in diameter, this windsock assembly model accommodates various needs. For larger windsocks, consider our HA-120RG model.
  6. Efficient wind inflation: The windsock’s taper ensures full inflation, even in wind speeds as low as 15 knots, enhancing visibility and accuracy.
  7. Strong endurance: HA windsock sleeves have demonstrated durability against wind speeds exceeding 145km/h (75 knots), proving their reliability.
  8. Thorough testing: Windsock fabrics undergo comprehensive testing by an independent laboratory, ensuring mechanical strength, UV resistance, and colorfastness.
  9. Brut frame (without coating) with customizable windsock colors: Windsock offered in various color choices (red/white, solid orange, or other colors available upon request).

Embrace the HA-80RG Windsock Assembly as your dependable wind direction indicator. Holland Aviation’s commitment to quality ensures that you receive a product that meets your expectations and needs. Experience simplicity and accuracy with this windsock assembly – a true reflection of Holland Aviation’s dedication to quality.



Datasheet

Where to use windsocks

Additional information

Mast diameter

Ø80mm

Mast length

Standard 4800mm, or any other length on request (max. 5800mm)

Mast material

6060 Aluminum

Foundation material

Galvanized steel

Mast support material

Galvanized steel

Windsock Frame Material

AISI 316 Stainless Steel

Swivel Bearings

2 Heavy Duty Stainless Steel Bearings

Available Lighting Styles

Internally Lighted, Externally Lighted, Unlighted

Power supply

100-240VAC, 6,6A

Power consumption

External lighting 40 Watt, Internal lighting 20 Watt LED, Obstruction light 5 Watt LED

Compliances

ICAO Annex 14 Vol I Aerodromes, ICAO Annex 14 Vol II Heliports, EASA ADR, EASA CS-HPT-DSN, FAA AC 150/5345-27, UK CAP 168, UK CAP 437
